Alpha Series 5202: product and installation guide
Alpha Series A1011 is a 5202 LED bulb sold individually, with 6500K white light. Its published 9,336-lumen figure is for a pair, so the measurement unit must be kept separate from the single-bulb sales quantity.
- SKU: A1011
- Sales quantity: One 5202 LED bulb per item ordered
- Published output: 9,336 lumens per pair
- Colour: 6500K white
- Listed power: 65W per bulb
- Listed cross-references: 2504 and PSX24W; compare original mounting and connector
- Cooling/control: Dual red copper heat plates, vacuum-sealed copper tubes and I-Driver system
Compare the installed bulb marking, connector, retainer and available space before removing the original lamp. Test the appropriate lighting functions and check the final beam aim after fitting. A bulb-base match alone does not establish suitability for every housing or lighting circuit.
Frequently Asked Questions
Does the 9,336-lumen rating mean a pair comes in the package?
No. The product is sold individually. The published output rating describes a pair; it does not change the sales quantity to two bulbs.
Is 9,336 lumens the output of one A1011 bulb?
No. The stated measurement is 9,336 lumens per pair. Do not relabel it per bulb or treat a calculated half-value as a separate tested measurement.
Can I select this bulb from a 2504 or PSX24W marking?
Those references are listed alongside 5202. Compare the actual base, locking tabs, connector and housing space as well; a cross-reference alone does not establish every lamp installation.
What white-light colour does this exact product use?
This exact listing specifies 6500K white light. Match the SKU and product generation when replacing a bulb; another Alpha Series product can use a different colour specification.
Does this bulb product replace a complete factory LED headlight?
It is intended for a compatible serviceable-bulb application. A factory LED assembly can have integrated electronics and light sources that do not use a replaceable bulb of this type. Inspect the installed equipment first.
Will these bulbs prevent every dashboard warning or flicker?
Results depend on the actual lighting circuit and connections. Diagnose any warning or flicker before selecting an additional module, and check the physical lamp application separately.
What warranty applies to this exact Alpha Series product?
This product carries a lifetime limited warranty. The existing terms and exclusions for the purchased SKU apply.
What should I check before fitting this bulb?
Compare the mounting and retaining arrangement, connector and space behind the lamp. The original dust cap must fit correctly, and cooling parts or attached electronics need adequate clearance. Check the final beam aim after installation.
