Diode Dynamics P13W HP48 LED Bulbs – Plug-and-Play Cosmetic Upgrade for Fog Lights & DRLs
The Diode Dynamics P13W HP48 LED pair provides a cosmetic change to 6000K cool white light. Its 48 Epistar 3014 LEDs and reflector cap distribute light around a compatible fog-light or daytime-running-light housing.
🔧 Key Features:
✔ Modern LED Styling
-
Upgrades factory yellow halogens to a clean, white 6000K color.
-
Designed for compatible fog-light and daytime-running-light applications.
✔ Omnidirectional Beam Output
-
270° illumination for smooth, uniform light distribution.
-
Top cap design redirects light for better reflector performance.
✔ Easy Plug-and-Play Installation
-
Manufacturer-listed cross-references: P13W, P13, 12277, PSX26W and 40-343. Match the actual holder, connector and clearance.
-
OEM-size connector; confirm the bulb seats correctly and any lamp cover closes.
✔ Built for Longevity & Reliability
-
Equipped with constant-current circuitry and transient voltage suppression.
-
Rated for operation in harsh environments from -40°F to 185°F.
✔ Trusted Quality from Diode Dynamics
-
Diode Dynamics reports measured lumen output from its in-house testing.
📦 Product Specs:
-
Bulb Size: P13W
-
LED Count: 48 x Epistar 3014 LEDs
-
Manufacturer-listed measured output: 250 lumens per bulb.
-
Color Temp: 6000K (Cool White)
-
Beam Angle: 270° (Omnidirectional)
-
Power Draw: 4.7W
-
Voltage Range: 9–16V
-
Current Draw: 0.35A @ 13.2V
-
Connector: OEM Plug-and-Play
-
Operating Temp: -40°C to 85°C (-40°F to 185°F)
-
Manufacturer warranty: Diode Dynamics three-year replacement limited warranty, subject to its terms.
-
Quantity: 2 bulbs
Application Notice:
This is a cosmetic fog-light or DRL bulb. Diode Dynamics advises against low- or high-beam headlight use.
Does this pair replace a complete LED lamp assembly?
This listing contains two replacement bulbs. Confirm that the actual lamp uses removable bulbs matching the listed designation; a similar vehicle model or lamp shape does not confirm a replacement for an integrated LED assembly.
