MORIMOTO EVO HYBRID · LF2-508Y
Quad-projector lighting. A clean Super Duty signature.
A complete left/right Evo Hybrid headlight pair for your 2020–2022 Ford Super Duty. Fixed white daytime running lights and fade-off turn signals keep the choice straightforward, with optics built for the exact application.
- Left + rightOne complete headlight pair
- Fixed white DRLsFade-off signals
- Four Bi-LED opticsIn each headlight

LIGHT WITH A PURPOSE
Four projectors in every housing.
Optics for the application
Each headlight uses four Bi-LED projectors for low and high beam. The Hybrid keeps this quad-projector layout; it does not drop down to a dual-projector system.
A complete assembly upgrade
Both housings and the listed installation hardware are supplied. This is a headlight-pair replacement, not a bulb conversion.
Aim is part of installation
Set the beam aim after fitting the lamps. Factory mounting points do not guarantee correct aim, especially when the truck’s ride height has changed.

INSIDE THE HOUSING
How the light is produced
The manufacturer’s optical illustration explains the layout. It is not a measured output test or a promise of performance in every condition.

YOUR FRONT-END SIGNATURE
Fixed white. Clean fade-off signals.
This Hybrid uses fixed white daytime running lights and amber fade-off turn signals. It does not include configurable DRL keys, lens heating or a standard startup welcome sequence.
Morimoto identifies a welcome sequence with the optional Supercharged drivers on this exact application. Those drivers remain an off-road-only configuration.

CHOOSE THE FEATURES YOU WANT
Compare the matching Evo family
This listing is the LF2-508Y Evo Hybrid. Other versions are separate products, with different lighting functions and compliance details. On smaller screens, swipe across the table to compare every column.
| Feature | XB Evo | XRGB Evo | XB Evo Hybrid |
|---|---|---|---|
| Daytime running lights | White / amber selectable | RGB app + white / amber modes | Fixed white |
| Turn signals | Sequential or fade-off selectable | Sequential or fade-off selectable | Fade-off |
| Lens heating | Frost-Free; driver-requested | Not included | Not included |
| Standard welcome sequence | Included | Included | Not included |
| Main optics | Four Bi-LED projectors | Four Bi-LED projectors | Four Bi-LED projectors |
| Manufacturer compliance | Standard-driver DOT/FMVSS108 configuration | Not DOT compliant | Standard-driver DOT/FMVSS108 configuration |
Supercharged drivers are optional and off-road only in Canada and the United States. Choosing white or amber DRLs does not make an XRGB assembly DOT compliant.
Compare LF2-508 heated XB Evo · Compare LF2-508R XRGB Evo

BEFORE YOU ORDER
Match the year, model and original lamps
| Vehicle | Manufacturer-listed application |
|---|---|
| Ford F-250 Super Duty | 2020-2022 |
| Ford F-350 Super Duty | 2020-2022 |
| Ford F-450 Super Duty | 2020-2022 |
Developed for North American left-hand-drive vehicles using right-hand traffic. Morimoto does not guarantee fitment outside North America.
The guide has separate factory-halogen and factory-LED wiring steps. Match the original lamps and connectors before fitting the supplied adapters and resistors.
The year range is specific: 2020–2022 Ford Super Duty. The 2017–2019 and 2020–2022 Super Duty pairs are separate applications.
BOTH SIDES. THE MATCHED HARDWARE.
What is supplied

- Headlights: One Pair (1x RH / Passenger Side Headlight, 1x LH / Driver Side Headlight)
- Accessories: 2x Halogen Adapter Harnesses, 2x Magnet Mount Resistors, 1x Fuse Tap, 1x DRL Harness
Use the adapters and signal components appropriate to the truck’s original lighting. Optional Supercharged drivers and other accessories are separate selections; they are not required to complete the standard headlight pair.
FACTORY MOUNTING. CAREFUL WIRING.
Plan the installation, then set the aim
- Identify the truck’s original lighting equipment and follow the matching branch in the official guide.
- Mount both housings at the original locations and connect the specified input harnesses, resistors and DRL components.
- The Ford guide calls for a notch in the fuse-box lid to route the DRL wire and grommet. Original mounting points do not mean a completely modification-free installation.
- Secure wires away from heat and moving parts, test every lighting function, then adjust beam aim.
Download the official LF2-508 model-family installation guide
The shared guide includes heated Evo instructions, but lens-heater activation does not apply to this nonheated Evo Hybrid.

AN OPTIONAL OFF-ROAD CONFIGURATION
Choose the matching Supercharged pair
The matching optional accessory is LF2-DRVSC28. Standard LED drivers are already included. The optional pair replaces them when you select the Supercharged configuration.
For this exact application, Morimoto describes approximately 30% greater low/high-beam intensity. That is the manufacturer’s comparison, not a BTS measurement or a guarantee in every condition.
The optional drivers also enable a multistage welcome sequence on this Hybrid, according to its exact manufacturer description.
THE EXACT LF2-508Y CONFIGURATION
Specifications and replacement references
| Detail | Manufacturer specification |
|---|---|
| Traffic Pattern | LHD / Right Hand Traffic Only (US/CA Standard) |
| Output (Standard Drivers) | DOT (FMVSS108) Compliant (LB2V and UB2) |
| Output (Supercharged Drivers) | Off-Road use only |
| Main Optics | 4x Type 1 Ishida Optic Bi-LED |
| Functions | Low, High, Park, Turn, and DRL |
| Turn Signal Modes | Fade-Off (Fixed) |
| DRL Color | White (Fixed) |
| Internal Finish | Black |
| Side marker | Amber side reflex reflector (DOT compliant) |
| Lens Details | Polycarbonate with proprietary anti-UV hard coating |
Original-equipment replacement references
LC3Z13008B, LC3Z13008A, LC3Z13008K, LC3Z13008M, LC3Z13008J, LC3Z13008L
Cross-check the references against the year, model and original lamp equipment above.
Morimoto provides a 5-year limited manufacturer warranty. Coverage, exclusions and return authorization follow the manufacturer’s current policy. Keep your proof of purchase and contact BTS before removing a lamp for a suspected warranty issue.
SEE THE DESIGN
Watch the official overview
Morimoto’s official Super Duty model-family presentation. Other versions may appear; use the exact package and specifications on this page for your selection.

The video loads only when you choose it. No autoplay. Product-family demonstrations may include other options; the exact package and compatibility notes on this page govern your selection.
CLEAR ANSWERS BEFORE CHECKOUT
Your Evo Hybrid questions
Is this one lamp or a complete pair?
One order supplies both driver-side and passenger-side headlight assemblies with the listed accessories.
Which trucks does this exact part fit?
2020–2022 Ford Super Duty. Match the exact factory headlight type and the equipment-specific branch in the official guide.
Does the Hybrid keep four projectors?
Yes. Each Super Duty Hybrid housing retains four Bi-LED projectors for low and high beam.
Does this exact version have heated lenses?
No. This Evo Hybrid does not include lens heating, even though the model-family guide also covers heated Evo lamps.
Are the Supercharged drivers included?
No. Standard drivers are included. LF2-DRVSC28 is the exact optional Supercharged pair, for off-road use only in Canada and the United States.
Does this Hybrid have a welcome sequence?
The standard Hybrid does not. Morimoto identifies a multistage welcome sequence with the optional Supercharged drivers, which are for off-road use only.
Is installation completely modification-free?
No. The factory mounting points are used, but the exact guide requires a notch in the fuse-box lid for the DRL wire. Follow the equipment-specific wiring instructions and aim the lamps.
What is the manufacturer’s road-use configuration?
Morimoto identifies the included standard-driver configuration as DOT/FMVSS108 compliant for its listed North American application. Optional Supercharged drivers exceed those intensity limits and are for off-road use only in Canada and the United States.
What warranty is included?
Morimoto lists a five-year limited manufacturer warranty. Keep proof of purchase and contact BTS for installation help or a suspected warranty issue.
