NX832 – 32″ Dual Row LED Light Bar (12–24V, 11,973 Lumens, Combo Beam)
Massive Output. Long Distance. Built for Serious Lighting Needs.
The NX832 32″ Dual Row LED Light Bar is a powerhouse auxiliary light designed for drivers who demand maximum brightness and exceptional beam coverage. Delivering 11,973 raw lumens with a high-performance combo beam, this light bar casts a wide flood pattern across the foreground while pushing a piercing spot beam up to 790 meters at 1 Lux down the centerline.
Featuring Osram OSLON® LEDs, a rugged dual-row configuration, and both side and bottom mount brackets, the NX832 is ideal for bull bars, roof racks, bumpers, or utility setups that require extreme performance and versatile mounting.
Key Features & Benefits
-
Extreme Output: Blasts out 11,973 raw lumens for unmatched visibility on trails or highways.
-
Combo Beam Design: Wide-angle flood + focused spot beam offers total forward coverage and long-range clarity.
-
Long-Range Reach: Beam reaches 790m at 1 Lux — perfect for high-speed or remote-area driving.
-
Dual Row Construction: Packs more LEDs into a compact form for increased brightness and beam density.
-
Premium LED Tech: Uses Osram OSLON® LEDs for efficiency, brightness, and durability.
-
Universal Mounting Options: Includes side and bottom brackets for flexible installs on nearly any surface.
-
All-Weather Build: IP67 & IP69K waterproof rating withstands pressure washing, dust, mud, and rain.
-
Shock & Vibration Resistant: Built tough for harsh off-road and work environments.
-
Clean 5700K White Light: Natural daylight color temp improves clarity and reduces eye fatigue.
-
Electronics Friendly: Certified to R10 EMI standards for interference-free operation with radios and electronics.
-
3-Year Warranty: Covered by Noxsolis for long-term durability and performance.
Built for Drivers Who Go Further
The NX832 Dual Row Light Bar is your all-in-one lighting solution for off-road exploration, nighttime work, or on-highway safety. Its powerful combo beam ensures no terrain or hazard is left unseen, while the durable construction means it keeps working even in the harshest conditions.
It’s the go-to choice for off-roaders, farmers, commercial fleets, and long-haul operators who expect more from their lighting gear.
Vehicle & Application Compatibility
Ideal for:
-
4WDs, UTVs, and off-road rigs
-
Pickup trucks, service vehicles, and overland builds
-
Agricultural and industrial machinery
-
Trailers, utility bodies, and heavy-duty work trucks
-
Bull bars, racks, roof mounts, and bumper installs
Compatible with 12V and 24V DC systems.
Technical Specifications
-
Light Output: 11,973 Lumens (Raw)
-
Beam Distance: 1 Lux @ 790m
-
Beam Type: Combo (Spot + Flood)
-
Power Consumption: 240W
-
Current Draw: 11.23A @ 13.8V / 6.45A @ 24V
-
Circuit Type: Dual
-
LED Type: Osram OSLON®
-
Color Temperature: 5700K
-
Voltage Range: 12–24V DC
-
Waterproof Rating: IP67 & IP69K
-
Lens Material: Polycarbonate
-
Mounting Options: Side brackets & bottom mount brackets
-
Connector: 2-Pin Deutsch DT
-
Weight: 2.05kg
-
Warranty: 3-Year Limited Warranty
What’s Included
-
1x NX832 32″ Dual Row LED Light Bar (Combo Beam)
-
1x Pair of Side Mounting Brackets with Hardware
-
1x Pair of Bottom Mounting Brackets with Hardware
Now Available at BTS Lighting — Go Big. Go Bright. Go Anywhere.
The NX832 is built for serious drivers who demand intense lighting performance in a durable, flexible, and rugged design. Whether you’re crossing backcountry trails or lighting up a jobsite, this bar has the power and reach to get the job done.
