United Pacific · 31224 / 31225
Included halogen bulbs and amber LED position bars
This black Columbia assembly combines included halogen main-beam bulbs with dual-function amber LED bars. The bars’ higher-intensity function can be wired to the turn signal; choose one side.
Included halogen bulbs
H7 low beam, H1 high beam and 3157 turn-signal bulbs are included.
Dual-function amber bars
The amber position bars have a higher-intensity function for a turn-signal connection.
Separate position wiring
The bar’s positive position feed must be independent of the OE harness.

Fitment & selection
Match the original headlight
- Freightliner Columbia: 2001–2011
For 2012–2020 or another year outside this list, confirm the original assembly, connector and bulb configuration with BTS before ordering.
| Driver | 31224 · one headlight assembly |
|---|---|
| Passenger | 31225 · one headlight assembly |
Installation & aiming
Use the original main-beam and signal/parking connections. Wire the position-light feed independently of the OE harness, and follow the guide for the optional high-function turn connection. Check both beam adjusters.
Lighting details
Specifications
| Low beam | H7 included · 46.8W · 3.9A at 12V |
|---|---|
| High beam | H1 included · 54W · 4.5A at 12V |
| Turn signal | 3157 bulb included |
| Position lighting | Dual-function amber LED bars |
| Finish | Black Inner Housing |
| Package | One headlight assembly for the selected side |
Product questions
Before you order
Does the price include both headlights?
No. Each option supplies one headlight for the selected side. Choose both sides separately if you need a pair.
Which model years should I check?
Use the application list above and match the original housing, mounting and connector. Confirm any year outside that list with BTS before ordering.
Are the main beams LED?
No. The main beams use the bulb types listed above. Any LED bars or signal lights are separate functions.
2-year manufacturer warranty
United Pacific lists a 2-year warranty for this headlight design. Keep your purchase information and contact BTS Lighting for product support.
