Diode Dynamics 9005 HP48 LED bulb pair
The 9005 HP48 provides a cosmetic change to 6000K cool white light. This DD0128P pair contains two bulbs, each using 48 Epistar 3014 LEDs and a top reflector that directs light outward and backward within the lamp.
Manufacturer-listed specifications
- Pair SKU: DD0128P
- Bulb designation: 9005
- Measured output listed by Diode Dynamics: 250 lumens
- Light colour: 6000K Cool White
- Light distribution: omnidirectional, 270 degrees
- Power: 4.0W
- Input voltage: 9–16V
- Current: 0.33A at 13.2V
- Operating temperature: -40°C to 85°C (-40°F to 185°F)
- Connector: OEM-size plug-and-play type
- Manufacturer warranty: three-year replacement limited warranty, subject to its terms
Match the application and connection
As one documented application, Diode Dynamics lists this exact pair for the daytime running lights of the 1995–1998 Nissan 240SX. Other vehicles, lamp positions and aftermarket housings need their own application check.
The manufacturer’s exact bulb cross-reference list is: 9005XS, 9005, 9011, 9005CB, 9005XSCB, 9005SU, 9005L+, 9005ST, 9005XV, 9005EB, 9005XSST. These references identify bulb designations; compare the actual connector, holder and clearance before ordering.
The bulb uses constant-current circuitry and transient suppression. Check the vehicle’s lighting circuit if a warning or flicker occurs; diagnose the cause before choosing additional electrical components. Confirm that the bulb seats correctly and any lamp cover closes.
Browse LED bulbs by listed base.
Can I use the HP48 as a high-beam upgrade?
Diode Dynamics describes HP48 as a cosmetic upgrade and says it is not bright enough to serve as the primary light source for nighttime driving. A matching 9005 base alone does not establish suitability for a headlight application.
