Diode Dynamics Heavy Duty Single Output 2-Pin Offroad Wiring Harness
Product Overview
Power your offroad lighting with confidence using the Diode Dynamics Heavy Duty Single Output 2-Pin Offroad Wiring Harness. Specially engineered for use with Diode Dynamics Stage Series light bars and LED pods (without backlight), this robust wiring harness offers a simple plug-and-play solution for clean, professional installs. Featuring high-capacity 14AWG wiring, a durable Deutsch DT connector, and built-in electrical safeguards including a 30A waterproof fuse and 60A 12V relay, this harness ensures reliable performance in even the harshest environments. Includes a two-way toggle switch for easy control and black wire sheathing for added protection.
Key Features & Benefits
-
Designed for Diode Dynamics Stage Series: Powers light bars and pods without backlighting.
-
Plug-and-Play Setup: Includes Deutsch DT 2-pin connector for quick, secure installation.
-
Heavy-Duty Wiring: Built with 14-gauge high-capacity wire for durability and power delivery.
-
Integrated Safety Components:
-
30A Waterproof Fuse
-
60A 12V Relay
-
-
Toggle Switch Included: Two-way switch allows convenient on/off operation.
-
Protective Black Sheathing: Shields wires from abrasion, moisture, and road debris.
-
Supports up to 25A Load: Capable of powering large single-output Stage Series lights.
-
Compatible with 12V Systems: Relay must be replaced for 24V system applications.
-
3-Year Warranty: Worry-free performance backed by Diode Dynamics.
-
100% Satisfaction Guarantee: Risk-free with a 30-day return policy and no restocking fee.
Expanded Benefit Section
Engineered for rugged conditions, the Diode Dynamics Heavy Duty 2-Pin Wiring Harness offers reliable power delivery to your offroad lighting setup. With OEM-grade connectors and weather-resistant design, this harness eliminates guesswork during installation and ensures long-term durability. The included fuse and relay protect your vehicle’s electrical system from overcurrent, while the included switch offers simple control from the cabin. Whether you’re running pods or large light bars, this harness supports up to 25 amps of power—enough for even the most demanding setups.
Compatibility
-
Designed for: Diode Dynamics Stage Series LED light bars and pods (non-backlit)
-
Voltage: 12V systems
-
Note: For 24V applications, replace relay with compatible 24V relay (not included)
Technical Specifications
-
Item Name: Heavy Duty Single Output 2-Pin Offroad Wiring Harness
-
Wire Gauge: 14 AWG
-
Output Connector: Deutsch DT (2-pin)
-
Fuse: 30A waterproof inline fuse
-
Relay: 60A, 12V
-
Max Load Capacity: 25A
-
Switch: 2-way toggle switch included
-
Sheathing: Black protective wrap
-
Voltage Compatibility: 12V standard (24V requires relay replacement)
-
Warranty: 3-Year Replacement Limited Warranty
-
Return Policy: 30-Day Return, No Restocking Fee
What’s Included
-
1x Heavy Duty Wiring Harness
-
1x Toggle Switch
-
Pre-installed 30A Fuse & 60A Relay
-
Deutsch DT Connector
Rugged Power for Serious Lighting
From Stage Series pods to full-width LED light bars, this Diode Dynamics 2-Pin Harness delivers dependable power, protected wiring, and quick install convenience—backed by a 3-year worry-free warranty and the trusted Diode Dynamics name.
