Bright & Reliable
Provides dependable illumination for real-world driving conditions.
Easy Installation
Simple plug-and-play installation across model years.
Smart Design
Combines advanced lighting performance with a distinctive visual signature.
Performance that delivers
Engineered with Purpose.
The 8800 EVO-X features industry-leading JWS Dual Burn®
technology, delivering wide low beam spread with powerful high beam punch.
SmartHeat® Technology
Industry leading technology that helps prevent snow and ice buildup on the lens.
Dual or Multi Purpose
Chose from Hi/Lo Beam Heated Headlight, or 5-in-1 Heated (lo/hi) Headlight, with black or chrome bezel options.
Multi-Application
- Agriculture
- Automotive
- Construction
- Industrial
- Mining
- Motorcycle
- Off-Road 4×4
- Powersports
- Specialty Vehicles
- Truck & Bus
- Commercial Truck
- Material Handling
- Railroad
Model 8800 4” x 6” EVO-X
LED Lo/Hi Beam Heated Headlight
Full brightness at minimum voltage.
$430 USD
Electrical Specifications
Current Draw:
5.29A @ 12V AC (Low Beam)
4.33A @ 24V AC (Low Beam)
7.72A @ 12V AC (High Beam)
5.41A @ 24V AC (High Beam)
0.26A @ 12V AC (Front Position)
0.15A @ 24V AC (Front Position)
Photometric Specifications
Raw Lumen Output: 3,740 (High beam), 2,330 (Low Beam)
Effective Lumen Output: 1,300 (High Beam), 670 (Low beam)
Candela Output: 57,000
Nominal LED Color Temperature: 5700 K
Beam Pattern(s):
Forward Lighting – High Beam (DOT/ECE)
Forward Lighting – Low Beam (DOT/ECE)
Signalization – Front Position
Model 8800 4” x 6” EVO-X
LED 5-in-1 Heated Headlight
Full brightness at minimum voltage.
$430 USD
Electrical Specifications
Input Voltage: 12-24V DC
Operating Voltage: 9-32V DC
Current Draw:
5.29A @ 12V DC (Low Beam)
4.33A @ 24V DC (Low Beam)
7.72A @ 12V DC (High Beam)
5.41A @ 24V DC (High Beam)
0.26A @ 12V DC (Front Position)
0.15A @ 24V DC (Front Position)
5.72A @ 12V DC (DRL)
4.48A @ 24V DC (DRL)
2.95A @ 12V DC (Direction Indicator)
1.53A @ 24V DC (Direction Indicator)
Photometric Specifications
Raw Lumen Output: 3,740 (High beam), 2,330 (Low Beam)
Effective Lumen Output: 1,300 (High Beam), 670 (Low beam)
Candela Output: 57,000
Nominal LED Color Temperature: 5700 K
Beam Pattern(s):
Forward Lighting – Daytime Running Light
Forward Lighting – High Beam (ECE)
Forward Lighting – Low Beam (ECE Right Hand)
Signalization – Front Position
Signalization – Turn (Front)
JW Speaker
Model 8900 EVO-X Headlight
The 8900 EVO X™ delivers maximum presence in a 5″ x 7″ LED headlight format designed for both OEM vehicle programs and aftermarket upgrades.
Tech specs
Features
Built with a modular optic design, the 8800 EVO X™ simplifies vehicle integration across OEM programs and aftermarket upgrades.
Ease of Use
- Daylight-level performance
- Modular optic design
- Simple plug-and-play installation
- All forward lighting functions; 5 in 1
Industry Leading Technology
- Industry-leading SmartHeat® technology helps prevent snow and ice buildup on the lens
- Industry-leading J.W. Speaker Dual Burn®; low beam spread, high beam punch
Competencies
- Full brightness at minimum voltage
- Dual compliance – DOT & ECE (Direction indicator (DI) is not DOT compliant)
- Buy American Act compliant
01. 2 Year Warranty
EVO-X Heated Headlights come with a limited 2-year warranty for added peace of mind.
02. Universal Fitment
Designed for universal fitment, the Model 8800 EVO-X Headlight seamlessly installs in standard 4″ x 6″ housings.
03. Premium Quality
Built with premium materials and engineered for a wider, uniform beam pattern, Evo‑X headlights provide increased usable light and dependable performance even in demanding conditions.
