Why Choose the J.W. Speaker Model 95 LED Fog Light Kit
The J.W. Speaker Model 95 is built for truck owners, fleets, and repair shops replacing halogen 90mm fog lights with a premium LED fog light solution. It is designed as a drop-in replacement for compatible 90mm halogen lights used on select buses, trucks, motor coaches, and heavy-duty truck applications.
For Peterbilt 579, Peterbilt 587, and Kenworth T660 owners within the listed retrofit range, this kit offers a serious LED fog light upgrade with solid-state optics, low current draw, shock and vibration resistance, IP69K sealing, and verified SAE/ECE fog light compliance.
Key Features & Benefits
Built as a 90mm LED Fog Light Replacement
The Model 95 is designed as a drop-in LED replacement for compatible halogen 90mm lights. This makes it a strong option for heavy-duty trucks and buses using 90mm fog light applications.
Fits Select Peterbilt and Kenworth Applications
The supplied retrofit information lists the Model 95 kit for the following semi truck applications:
- 2013-2015 Peterbilt 579
- 2011-2015 Peterbilt 587
- 2008-2015 Kenworth T660
Always confirm your truck year, existing light size, mounting setup, and wiring before ordering.
J.W. Speaker Solid Optics Technology
The Model 95 uses J.W. Speaker solid optics technology to produce a precise engineered fog beam pattern. This makes it a purpose-built fog light, not a generic auxiliary light.
607 Effective Lumens
The Model 95 fog light is rated at 1,435 raw lumens and 607 effective lumens based on the supplied photometric data. Effective lumens are the more useful output number because they reflect usable light after optical losses.
5000K LED Color Temperature
The Model 95 uses a nominal 5000K LED color temperature. This gives the fog light a clean white output while staying within the verified product data.
12–24V DC Compatibility
This LED fog light has a 12–24V DC input voltage and a 10–30V DC operating voltage range. Current draw is listed at 1.25A at 12V DC and 0.7A at 24V DC.
Lower Power Draw Than Stock Halogen Lights
The supplied overview states the Model 95 uses 75–80% less power than stock halogen lights. This makes it a strong upgrade path for buyers replacing older 90mm halogen fog lights.
Shock and Vibration Resistance
The Model 95 is built to resist shock and vibration, helping extend the service life of the lights in heavy-duty truck, bus, and specialty vehicle applications.
SAE J583 and ECE Reg 19 Compliance
The supplied product data lists SAE J583 and ECE Reg 19 regulatory standards for the Model 95 fog light. These standards support road-use visibility, durability, and reliability requirements for compatible applications.
IP69K Sealed Design
The Model 95 is sealed to IP69K based on the supplied product data. This is a strong protection rating for heavy-duty vehicles exposed to water, road spray, washdowns, and harsh working environments.
Made in the USA
The supplied overview states the Model 95 is made in the U.S.A. This is a strong trust signal for buyers looking for premium J.W. Speaker truck lighting.
Performance / Compatibility / Use Case
Best Use: Premium 90mm LED Fog Light Upgrade
The Model 95 is best used as a premium LED replacement for compatible halogen 90mm fog lights. It is suited for heavy-duty trucks, buses, motor coaches, and specialty vehicles where the existing light size and fitment match the Model 95 retrofit requirements.
Peterbilt 579, Peterbilt 587, and Kenworth T660 Retrofit Applications
The supplied retrofit data lists the following compatible semi truck applications:
- 2013-2015 Peterbilt 579
- 2011-2015 Peterbilt 587
- 2008-2015 Kenworth T660
Do not assume fitment outside these listed ranges unless confirmed by J.W. Speaker or the product listing.
Fog Beam Pattern
This Model 95 product data lists the beam pattern as Forward Lighting – Fog. It should be optimized and merchandised as a fog light kit, not a high beam or general headlight page, unless a separate high beam SKU is being sold.
Model 95 Legal Usage Note
The supplied legal usage text states that DOT compliance for the Model 95 high beam requires the high beam to be used with stock headlights and turned off when facing oncoming traffic. Since this page is for the fog beam product data, avoid mixing high-beam compliance language into the fog light description unless the exact kit includes high beam components.
Installation / Fitment / Technical Details
Installation depends on your existing 90mm halogen light setup, truck year, mounting points, wiring, and connector compatibility. The Model 95 is designed for easy plug-and-play installation where the vehicle application and existing light setup match the listed retrofit requirements.
Technical specifications:
- Product type: 90mm LED fog light kit
- Input voltage: 12–24V DC
- Operating voltage: 10–30V DC
- Current draw: 1.25A at 12V DC, 0.7A at 24V DC
- Transient spike protection: 150V peak at 1 Hz, 100 pulses
- Red wire: Positive
- Black wire: Ground
- Raw lumen output: 1,435
- Effective lumen output: 607
- Candela output: 7,500
- Nominal LED color temperature: 5000K
- Beam pattern: Forward Lighting – Fog
- Regulatory standards: ECE Reg 19, SAE J583, IEC IP69K
- Retrofit applications: 2013-2015 Peterbilt 579, 2011-2015 Peterbilt 587, 2008-2015 Kenworth T660
Before ordering or installing, check:
- Truck year, make, and model
- Existing 90mm light setup
- Existing connector and wiring condition
- Mounting location and available space
- Whether the kit matches fog light or high beam requirements
- Whether you are replacing one side or both sides
- Final fog light aim after installation
Build Quality / Materials / Warranty / Trust Signals
The J.W. Speaker Model 95 uses a heavy-duty housing, UV-resistant lens, solid-state optics, IP69K sealing, and 12–24V DC electrical design. The supplied product data lists SAE J583, ECE Reg 19, IEC IP69K, and Made in USA details.
The provided data does not include a warranty term. Confirm warranty coverage before publishing if BTS has manufacturer warranty details available separately.
What’s Included
- J.W. Speaker Model 95 90mm LED fog light kit
- Fog beam configuration based on supplied product data
Package contents beyond the Model 95 fog light kit are not fully confirmed. Check the product listing or contact BTS Lighting to confirm whether this kit includes two lights, mounting hardware, connectors, or installation instructions.
Frequently Asked Questions
What is the J.W. Speaker Model 95 designed to replace?
The J.W. Speaker Model 95 is designed to replace compatible halogen 90mm lights used on trucks, buses, motor coaches, and specialty vehicles. Confirm your existing light size and mounting setup before ordering.
What trucks does the Model 95 fog light kit fit?
The supplied retrofit data lists 2013-2015 Peterbilt 579, 2011-2015 Peterbilt 587, and 2008-2015 Kenworth T660 applications. Do not assume fitment beyond those years unless confirmed by J.W. Speaker or BTS Lighting.
Is the Model 95 a fog light or headlight?
The supplied product data for this SKU lists the beam pattern as forward lighting fog. Optimize and sell this page as a Model 95 LED fog light kit unless a separate high-beam or headlight version is being listed.
Is the Model 95 plug-and-play?
The supplied overview describes the Model 95 as an easy plug-and-play installation for compatible 90mm replacement applications. Fitment still depends on your truck year, existing light setup, connector, and mounting configuration.
What is the lumen output of the Model 95 fog light?
The Model 95 fog light is rated at 1,435 raw lumens and 607 effective lumens. Effective lumens are the better number to use when judging usable output after optics and lens losses.
What color temperature is the Model 95?
The Model 95 has a nominal LED color temperature of 5000K based on the supplied product data. This gives it a clean white LED output.
Does the Model 95 work on 12V and 24V trucks?
Yes, the supplied electrical data lists 12–24V DC input voltage and a 10–30V DC operating voltage range. Current draw is listed at 1.25A at 12V DC and 0.7A at 24V DC.
Is the Model 95 road legal?
The supplied product data lists SAE J583 and ECE Reg 19 for the Model 95 fog light. Confirm the product markings, installation, and local requirements before road use.
Is the Model 95 water resistant?
The supplied product data lists IEC IP69K sealing for the Model 95. This is a high ingress protection rating for harsh road, washdown, and heavy-duty environments.
Is the Model 95 made in the USA?
Yes, the supplied overview states the Model 95 is made in the U.S.A.
