JW Speaker Model 735 LED Work Light — See Through Dust, Fog, and Darkness
Tackle the toughest work conditions with confidence using the JW Speaker Model 735 — a high-performance oval LED work light built for visibility in the harshest environments. Outfitted with a rugged amber lens and forward-facing trapezoid beam, this 12–24V work lamp delivers powerful, glare-reducing illumination designed for dusty, foggy, and off-road conditions.
From farms to freight yards, from 4×4 trails to mining pits, the Model 735 is the go-to lighting upgrade for professionals who demand durability, clarity, and field-proven performance.
🔧 Features & Benefits
Amber Bezel with Clear Glass Lens
Combines the rugged styling and anti-glare benefits of an amber bezel with a clear glass lens that resists scratches, UV degradation, and high-heat distortion.
Trapezoid Beam Pattern for Work Area Coverage
Forward-focused trapezoid optics produce a wide, horizontal beam ideal for illuminating paths, work zones, and jobsite perimeters — exactly where visibility matters most.
Die-Cast Aluminum Housing
Tough, corrosion-resistant housing shields internal components from shocks, vibrations, and environmental wear, making this lamp ideal for industrial and off-road use.
Weatherproof Deutsch Connector
Comes equipped with a sealed 2-pin DT04-2P socket and accepts the DT06-2S plug for secure, moisture-resistant installation on trucks, tractors, or specialty equipment.
Universal Pedestal Mounting
Includes a robust 5/16″-18 x 0.58″ mounting bolt and a pedestal mount, giving you flexibility to install on a wide range of vehicles and machinery.
Wide Voltage Compatibility
With an input range of 12–24V DC and operating voltage between 10–36V DC, the Model 735 integrates seamlessly into standard and heavy-duty electrical systems.
🚜 Applications & Vehicle Compatibility
The JW Speaker 735 is purpose-built for demanding environments where conventional lighting fails. Trusted by operators and technicians across multiple sectors, it’s ideal for:
-
Agricultural Equipment – Tractors, sprayers, harvesters
-
Construction Machinery – Loaders, graders, dozers
-
Mining Operations – Drills, haulers, underground machines
-
Industrial & Material Handling – Forklifts, cranes, yard trucks
-
Automotive & Off-Road 4x4s – Jeeps, ATVs, trail rigs
-
Railroad & Specialty Vehicles – Utility service trucks, maintenance fleets
⚙️ Technical Specifications
-
Shape: Oval
-
Lens Material: Clear Glass
-
Bezel Color: Amber
-
Housing: Die-Cast Aluminum (Black)
-
Mount Type: Universal Pedestal
-
Mounting Hardware: (1x) 5/16″-18 x 0.58″ Bolt
-
Connector Type: Integrated 2-Pin Deutsch DT04-2P
-
Mating Connector: DT06-2S
-
Input Voltage: 12–24V DC
-
Operating Voltage: 10–36V DC
-
Current Draw: 4.00A @ 12V / 2.00A @ 24V
-
Beam Pattern: Trapezoid (Forward Lighting)
-
Raw Lumens: 3,900
-
Effective Lumens: 1,000
-
Operating Temp: -40°C to 65°C / -40°F to 149°F
🔦 Why Choose the JW Speaker 735?
-
Exceptional performance in low-visibility environments
-
Amber lens boosts contrast in fog, dust, and stormy weather
-
Durable enough for mining, construction, and agricultural abuse
-
Trapezoid beam maximizes usable light coverage
-
IP-rated sealed connector for worry-free outdoor use
-
Backed by JW Speaker’s quality manufacturing standards
Whether you’re plowing fields, navigating dark job sites, or crawling through off-road terrain, the JW Speaker Model 735 brings light and clarity to every corner of your workday. This is professional-grade visibility, built for those who never clock out when the weather turns or the trail gets tough.
Power through the elements. Light it up with JW Speaker.
