Why Choose This 11 LED Headlight?
If you want to upgrade the look and function of your Kenworth T880, this black 11 LED headlight is a strong replacement option. It combines multiple lighting features into one assembly, giving your truck a more modern appearance along with improved front-lighting performance.
The black inner housing is ideal for drivers who want a stealthier, more aggressive front-end style without giving up integrated lighting functions.
Key Features & Benefits
11 LED Dual-Beam Headlight Performance
This headlight uses an 11 LED layout to provide low beam and high beam lighting for stronger road visibility.
- Low beam: 1,200 lumens
- Low beam power: 32W at 12V DC
- Uses 3 LEDs for low beam
- High beam: 2,400 lumens
- High beam power: 64W at 12V DC
- Uses 8 LEDs for high beam
This design is built to deliver strong beam performance with a sharp light pattern for road coverage.
Integrated Amber Turn Signal
This headlight includes a built-in amber turn signal for a cleaner all-in-one front-lighting setup.
- 10 amber LEDs
- 300 lumens
- 12W at 12V DC
White DRL Halo
A white halo-style daytime running light helps improve visibility and gives the headlight a more modern appearance.
- 202 white LEDs
Amber Sidemarker
The integrated sidemarker adds another functional lighting feature for improved side visibility.
- 6 amber LEDs
- P2 rated
Position Light
This headlight also includes a position light for additional low-light visibility.
- 100 lumens
- 5W at 12V DC
Black Inner Housing
The black inner finish gives this version a bolder, more aggressive look than the chrome version. It works well for blackout themes, custom builds, and drivers who want a darker front-end style.
Performance, Compatibility & Use Case
Fits 2015-2026 Kenworth T880 Models
This headlight is designed for Kenworth T880 trucks from 2015 through 2026.
- Fits Kenworth T880
- Fits 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025 and 2026 model years
- Available for driver side or passenger side
- Sold individually
Built for Work Trucks and Custom Builds
This is a strong option for replacing worn factory headlights, improving visibility, or giving your truck a more modern LED look with multiple integrated lighting functions.
Installation, Fitment & Technical Details
Plug-and-Play Installation
This headlight is designed to install using the existing factory wiring harness for plug-and-play headlight connection.
Pre-Installed Load Resistor
A load resistor is pre-installed to help reduce flickering and signal errors. Based on the product details provided, the resistor can be removed if you experience dimming or non-activation.
Technical Specifications
- Low beam: 1,200 lumens
- High beam: 2,400 lumens
- Turn signal: 10 amber LEDs
- DRL halo: 202 white LEDs
- Sidemarker: 6 amber LEDs
- Position light: 100 lumens
- Housing options: Chrome or Black
- Certifications: DOT / SAE, FMVSS 108
- Installation: Plug-and-play
- Warranty: 3 years
Build Quality, Materials, Warranty & Trust Signals
Multi-Function LED Housing
This headlight combines low beam, high beam, turn signal, sidemarker, position light, and DRL functions into one housing for a more complete upgrade and a cleaner overall look.
Compliance Information
Based on the product details provided, this headlight is listed as DOT approved and meets DOT / SAE and FMVSS 108 standards.
Warranty Coverage
This headlight includes a 3-year warranty.
What’s Included
- 1 x 11 LED headlight assembly
- Pre-installed load resistor
- Plug-and-play wiring harness
Please Note: This headlight is sold individually. Be sure to specify driver or passenger side and confirm the housing finish when ordering.
Frequently Asked Questions
What trucks does this headlight fit?
This headlight is designed for 2015-2026 Kenworth T880 models. It is available for either the driver side or passenger side.
Is this headlight sold individually or as a pair?
This headlight is sold individually. If you are replacing both sides, you will need to order the driver side and passenger side separately.
What is the difference between the black and chrome version?
The main difference is the inner housing finish. The black version gives the truck a darker, more aggressive appearance, while the chrome version offers a brighter, factory-inspired look.
Does this headlight include a DRL?
Yes. It includes a white halo-style daytime running light made up of 202 white LEDs.
Does this headlight include a turn signal and sidemarker?
Yes. It includes an integrated amber turn signal with 10 amber LEDs and an amber sidemarker with 6 amber LEDs.
What are the low beam and high beam outputs?
The low beam is rated at 1,200 lumens and the high beam is rated at 2,400 lumens. The low beam uses 3 LEDs and the high beam uses 8 LEDs.
Is this a plug-and-play headlight?
Yes. Based on the provided information, it is designed to install using the existing factory wiring harness.
Does it come with a load resistor?
Yes. A load resistor is pre-installed to help reduce flickering or signal errors.
Is this headlight DOT approved?
Based on the provided details, this headlight is listed as DOT approved and meets DOT / SAE and FMVSS 108 standards.
What comes in the box?
The package includes one 11 LED headlight assembly, a pre-installed load resistor, and a plug-and-play wiring harness.
