United Pacific · 34139
ULTRALIT-8 combined-beam headlight
Eight LEDs, combined high/low beams and polycarbonate construction in one 12V 4×6 lamp. Match the original lamp and installation before ordering; each purchase is one headlight.
Both beam functions
Low and high beam functions are combined in this single lamp.
One lamp per purchase
Sold individually, not as a pair or a complete four-headlight kit.
12V application
Check the original lamp reference and connector functions; this model is specified for 12V DC.

Fitment & installation
Match the original lamp
Compare the original lamp number and beam function, mounting bucket, retaining hardware, rear clearance and connector functions. A 4×6 size match alone does not establish fit. Keep the vehicle’s required lighting arrangement and check headlight aim after installation.
Manufacturer replacement references: H4651 / H4652 / H4656. Match low-beam, high-beam and ground functions to the truck’s circuit before connecting.
Lamp details
Specifications for one lamp
| Part number | 34139 |
|---|---|
| Beam function | Combined high / low |
| Electrical system | 12V DC |
| Package | One headlight |
| Replacement references | H4651 / H4652 / H4656 |
| Low beam | 500 lumens |
| High beam | 800 lumens |
| Construction | Polycarbonate lens and housing |
| Ingress rating | IPX7 |
| Manufacturer compliance listing | DOT/SAE · FMVSS108 |
Product questions
Before you order
Is this a complete four-headlight kit?
No. The package contains one lamp. Order the number required for the verified headlight arrangement.
Does a 4×6 opening guarantee fit?
No. The beam function, mount, retaining hardware, rear clearance and connector functions must also match.
Can this exact lamp be used on 24V?
This model is specified for 12V DC; do not treat it as a 24V lamp.
Warranty & alternatives
Three-year manufacturer warranty
United Pacific lists a three-year warranty for this lamp. Keep your purchase information and contact BTS Lighting for help with a product issue.
