Bring useful light to the sides of the trail
2021–2023 Ford F-150 · Stage Series ditch lights
Place a pair of auxiliary pods above the fenders with brackets designed around the truck’s existing mounting points. Choose a compact C2 kit, an SS3 kit, or the vehicle brackets on their own.

Choose the lamp family and package
SS3 Sport or Pro
Three-inch pods with a Combo main beam and separate Amber backlight. White and Yellow options have matching main-beam colours across the pair.
C2 choices
The existing C2 selections on this page are labelled C2 1.0 Sport and Pro. Confirm the exact C2 lamp revision with BTS before ordering; the current manufacturer catalogue also shows a newer C2 2.0 version under these kit numbers.
Already own compatible lamps? DD7364P is the vehicle-bracket option only. Select Bracket Only and No lamps (listed as None in the colour choices). It does not include lamps or wiring.


Main-beam colour and accent lighting are separate
White main beams are a cool 6000K; Yellow main beams are selective 3000K. The Amber backlight is a separate low-output accent circuit. It does not turn a White kit into a Yellow main-beam kit.


Use the auxiliary main beams off road. Keep them switched off when they could dazzle other road users.
Check mounting and clearance before ordering
This page’s illustrated guide covers the 2021, 2022 and 2023 F-150 mounting route. The vehicle brackets reuse the original top-fender mounting bolts. No new body hole is required for the supported bracket installation.
- Keep clearance between the bracket and painted fender.
- Verify the hood opens and closes freely before final tightening.
- Route all wiring outside the moving hood hinges.
- Do not use an automatic car wash with the kit installed.
- Confirm a modified hood, cowl or fender installation before ordering.
The existing listing also names Lightning and Expedition applications; confirm the exact year/model and mounting arrangement with BTS before using this F-150 guide on another vehicle.
What the selected package includes
A complete SS3 or C2 kit includes two selected pods, two vehicle brackets, the matching pod mounting brackets, a heavy-duty dual-output 4-pin harness and mounting hardware. The harness supports separate main-light/backlight control using the appropriate switch adapter supplied with the kit.
DD7364P supplies the two vehicle brackets only. Reuse suitable lamps, pod mounts and hardware, and supply the correct harness separately.

See the original mounting and routing photos
Our illustrated guide shows all five manufacturer technical photographs: protecting the paint, removing the fender bolt, positioning the bracket, routing outside the hinge, and checking pod/hood clearance.
F-150 ditch-light installation
Follow the shared bracket route, then use the hardware and wiring diagram supplied with your exact lamp revision.
Match the exact kit selection
| SKU | Kit choice | Main beam | Package |
|---|---|---|---|
| DD7365 | 2" C2 1.0 Sport | White Combo | Two pods + mounts + harness |
| DD7366 | 2" C2 1.0 Sport | Yellow Combo | Two pods + mounts + harness |
| DD7367 | 2" C2 1.0 Pro | White Combo | Two pods + mounts + harness |
| DD7368 | 2" C2 1.0 Pro | Yellow Combo | Two pods + mounts + harness |
| DD7369 | 3" Sport | White Combo | Two pods + mounts + harness |
| DD7370 | 3" Sport | Yellow Combo | Two pods + mounts + harness |
| DD7371 | 3" Pro | White Combo | Two pods + mounts + harness |
| DD7372 | 3" Pro | Yellow Combo | Two pods + mounts + harness |
| DD7364P | Bracket Only | No lamps | Vehicle brackets only |
Manufacturer warranty
Diode Dynamics provides a limited lifetime warranty for this product for eligible purchases from April 15, 2025. Commercial, industrial and fleet use is limited to 8 years. After the first 3 years, covered products require return for inspection and repair or replacement at the manufacturer’s discretion. Coverage applies to the specified lamp or component; bundled wiring and accessories follow their own published terms. Keep proof of purchase. Manufacturer approval and an RMA are required before return; labor and normal wear are excluded. Shipping obligations vary by location. See the manufacturer warranty terms for eligibility, exclusions and claim instructions.
Bundled wiring follows its separate published warranty terms; it is not automatically covered for the same period as an eligible lamp or bracket.
