Jeep Cherokee | Grand Cherokee | SS3 LED Fog Light Kit
Features
-
Direct replacement for Jeep Cherokee/Grand Cherokee fog lamps
-
SAE-compliant, road-legal output
-
Includes round bezel for factory-style appearance
-
Plug and play, no modification needed
-
Advanced TIR optics provide high efficiency and focus
-
Durable powder-coated aluminum die-cast housing
-
Engineered and assembled in the USA
Overview
Upgrade the fog lights on your Jeep Cherokee or Grand Cherokee with the SS3 Fog Light Bracket Kit. Delivering higher output intensity than any other 3” light on the market, these LED pods feature custom-engineered TIR optics for maximum performance and beam efficiency.
The included round bezel ensures a clean, factory-style appearance — only much brighter.
Plug and Play Installation
Thanks to the custom-molded brackets, the SS3 Fog Light Kit installs in minutes. Simply remove your factory fog light assembly and bolt in the SS3 replacement. Wire adapters are included to connect directly to your factory bulb sockets — no additional wiring required.
Advanced Optics & Efficiency
Unlike traditional reflectors or lenses that waste light through glare and internal loss, the SS3’s Total Internal Reflection (TIR) optic focuses every bit of light exactly where you need it. This design drastically improves efficiency and minimizes wasted output.
The TIR optic also serves as both the primary optic and lens, reducing losses and maximizing light intensity when paired with high-output LED chips.
Beam Pattern Options
-
SAE Driving: 18×8° beam designed to supplement high beams with wide, long-range output. Meets SAE J581 standard.
-
SAE Fog (FineLine Optic): Extremely wide 80° spread for full road coverage. Meets SAE J583 standard for fog lamps. Available in cool white or selective yellow for better performance in adverse weather.
Backlight Functionality
Each SS3 pod includes an integrated amber backlight. This accent feature fully illuminates the optic, providing a distinctive and modern look compared to small indicator LEDs on other products.
Power Level Options
-
Sport: Best value option with high-intensity LEDs
-
Pro: Double the total output for powerful illumination
-
Max: Cutting-edge emitters for extreme intensity and maximum performance
Reliability You Can Trust
-
Tested for long-term performance from -40°F to 185°F
-
Vibration, moisture, and corrosion tested to SAE standards
-
Proven by racers and enthusiasts in real-world conditions
With over a decade of experience, Diode Dynamics is a trusted name in LED lighting — delivering innovation, quality, and performance built in the USA.
What’s Included
-
(2) SS3 3” Round LED Pods
-
(2) Type M brackets
-
(2) 9006 DT Adapters
-
(2) 5202 DT Adapters
-
(2) Backlight Tap Wire Kits
-
Mounting hardware
-
Mounting guide
Quantity: Pair (Left and Right Side)
Warranty: Lifetime warranty
Return Policy: 30-day return with no restocking fee — 100% satisfaction guarantee
Fitment
Application: Fog Light Replacement
-
Make: Jeep
-
Models:
-
2014–2017 Jeep Cherokee
-
2011–2013 Jeep Grand Cherokee
-
⚠️ Note: This kit replaces OEM fog lamps. If your vehicle does not come equipped with fog lamps, additional hardware and wiring may be required.
Choose the correct Diode Dynamics configuration
| Manufacturer SKU | Configuration |
|---|---|
| DD7044 | SS3 Sport Type M Kit ABL White SAE Fog |
| DD7045 | SS3 Sport Type M Kit ABL Yellow SAE Fog |
| DD7047 | SS3 Pro Type M Kit ABL White SAE Fog |
| DD7048 | SS3 Pro Type M Kit ABL Yellow SAE Fog |
| DD7049 | SS3 Max Type M Kit ABL White SAE Fog |
| DD7050 | SS3 Max Type M Kit ABL Yellow SAE Fog |
Questions and answers
How do I choose the correct version?
Select the options that match the manufacturer SKU and configuration table on this page. The listed choices cover DD7044, DD7045, DD7047, DD7048, DD7049, DD7050; each row is a real product configuration.
What is included?
Two (2) SS3 3” Round LED Pods; Two (2) Type M brackets; Two (2) 9006 DT Adapters; Two (2) 5202 DT Adapters; Two (2) Backlight Tap Wire Kit; Mounting hardware; Mounting guide
What vehicle details must match?
Match the stated model years, model and any bumper, trim or factory-equipment requirements. A kit for one bumper or fog-light opening is not automatically compatible with another configuration of the same vehicle.
Explore pod lights, vehicle-specific lighting kits and matching wiring harnesses.
Manufacturer warranty
Diode Dynamics provides a limited lifetime warranty for this product for eligible purchases from April 15, 2025. Commercial, industrial and fleet use is limited to 8 years. After the first 3 years, covered products require return for inspection and repair or replacement at the manufacturer’s discretion. Coverage applies to the specified lamp or component; bundled wiring and accessories follow their own published terms. Keep proof of purchase. Manufacturer approval and an RMA are required before return; labor and normal wear are excluded. Shipping obligations vary by location. See the manufacturer warranty terms for eligibility, exclusions and claim instructions.
