Ford Excursion | Super Duty | Ranger-SS3 LED Fog Light Kit
Features
-
Direct replacement for Ford fog lamps including:
- 2000-2005 Ford Excursion
- 2004-2007 Ford Ranger
- 1999-2010 Ford Super Duty F-250/F-350
-
SAE-compliant, road-legal output
-
Includes custom bracket with bezel for factory-style appearance
-
Plug-and-play installation — no modification required
-
Advanced TIR optics for maximum efficiency and focus
-
Durable powder-coated aluminum die-cast housing
-
Engineered and Assembled in the USA
Overview
Upgrade the fog lights on your Ford with the SS3 Fog Light Bracket Kit! Featuring higher output intensity than any other 3” light on the market, these LED pods are built for performance. With custom-engineered TIR optics, you get powerful, road-legal beam patterns in a durable, factory-style package.
Plug-and-Play Installation
The custom-molded brackets allow for quick, easy installation in just minutes. Simply remove your factory fog light assembly and bolt in the SS3 kit. Wire adapters are included for seamless connection to your factory bulb sockets — no additional wiring needed.
Focused Performance
Traditional reflector and lens designs lose light to glare and internal reflections. The SS3’s custom TIR optic collects all light from the LED and projects it with precision, drastically reducing glare and maximizing usable output. The optic also doubles as the outer lens, improving efficiency and brightness compared to standard designs.
SAE-Compliant Beam Patterns
-
SAE Driving: Designed to supplement high beams with an 18×8° spread for clear, long-range visibility at speed.
-
SAE Fog (FineLine Optic): Provides an ultra-wide 80° spread with high-intensity output, fully illuminating the road ahead. Available in cool white (6000K) or selective yellow (3000K) for improved performance in poor weather.
When properly aimed and installed in pairs:
-
Driving White meets SAE J581 (Auxiliary High Beam).
-
Fog Pattern meets SAE J583 (Foglamp).
Backlight Functionality
Each SS3 pod includes a distinctive amber backlight, fully illuminating the TIR optic for a modern, stylish accent. The included harness lets you connect the backlight to your preferred vehicle function.
Output Options
-
White (6000K): Crisp, cool white — matches most factory LEDs.
-
Yellow (3000K): Selective yellow for better contrast in rain, fog, or snow.
Available in three power levels:
-
Sport: High-intensity LEDs at the best value.
-
Pro: Double the total power for serious output.
-
Max: Cutting-edge emitters delivering unmatched brightness and intensity.
Proven Reliability
Tested for performance and durability under extreme conditions:
-
Operating temps from -40°F to 185°F
-
Vibration, moisture intrusion, and corrosion resistance (SAE standards)
-
Real-world tested by racers and off-road enthusiasts
What’s Included
-
Two (2) SS3 3” Standard LED Pods
-
Two (2) Type SDX brackets
-
Two (2) 9006 DT adapters
-
Mounting hardware
-
Mounting guide
Quantity: Pair (Left and Right Side)
Warranty: Lifetime warranty
Return Policy: 30-day return with no restocking fee
Satisfaction: 100% Guarantee
Fitment
-
Application: Fog Light
-
Make: Ford
-
Model: 2000-2005 Ford Excursion, 2004-2007 Ford Ranger, 1999-2010 Ford Super Duty F-250/F-350
Note: This kit is a direct replacement for OEM fog lamps. Vehicles without factory fog lamps may require additional hardware and wiring for installation.
Choose the correct Diode Dynamics configuration
| Manufacturer SKU | Configuration |
|---|---|
| DD7100 | SS3 Sport Type SDX Kit ABL White SAE Fog |
| DD7102 | SS3 Sport Type SDX Kit ABL Yellow SAE Fog |
| DD7104 | SS3 Pro Type SDX Kit ABL White SAE Fog |
| DD7106 | SS3 Pro Type SDX Kit ABL Yellow SAE Fog |
| DD7107 | SS3 Max Type SDX Kit ABL White SAE Fog |
| DD7108 | SS3 Max Type SDX Kit ABL Yellow SAE Fog |
Questions and answers
How do I choose the correct version?
Select the options that match the manufacturer SKU and configuration table on this page. The listed choices cover DD7100, DD7102, DD7104, DD7106, DD7107, DD7108; each row is a real product configuration.
What is included?
Two (2) SS3 3” Standard LED Pods; Two (2) Type SDX brackets; Two (2) 9006 DT 4-Pin backlight tap wires; Mounting hardware; Mounting guide
What vehicle details must match?
Match the stated model years, model and any bumper, trim or factory-equipment requirements. A kit for one bumper or fog-light opening is not automatically compatible with another configuration of the same vehicle.
Explore pod lights, vehicle-specific lighting kits and matching wiring harnesses.
Manufacturer warranty
Diode Dynamics provides a limited lifetime warranty for this product for eligible purchases from April 15, 2025. Commercial, industrial and fleet use is limited to 8 years. After the first 3 years, covered products require return for inspection and repair or replacement at the manufacturer’s discretion. Coverage applies to the specified lamp or component; bundled wiring and accessories follow their own published terms. Keep proof of purchase. Manufacturer approval and an RMA are required before return; labor and normal wear are excluded. Shipping obligations vary by location. See the manufacturer warranty terms for eligibility, exclusions and claim instructions.
