NX801 – 11.5″ Slimline LED Light Bar (12–24V, 4,900 Lumens, Combo Beam)
Ultra-Slim. Seriously Bright. Built to Fit Anywhere.
The NX801 11.5″ Slimline LED Light Bar is engineered for tight mounting spaces where performance can’t be compromised. With a minimal 33mm profile, this ultra-slim light bar produces a powerful 4,900 raw lumens of crisp white light in a combo beam pattern that delivers both wide-area flood and long-distance spot illumination — reaching up to 450m at 1 Lux.
Perfect for bumpers, grilles, racks, and light-duty commercial applications, the NX801 offers premium visibility, rugged construction, and flexible mounting options in one compact package.
Key Features & Benefits
-
Slimline Profile: Just 33mm thick — ideal for low-clearance or discreet installs on modern bumpers and racks.
-
Powerful Combo Beam: Projects light up to 450m at 1 Lux, with a balanced mix of flood and spot lighting.
-
High Efficiency Output: 4,900 raw lumens from a 54W system for clear, wide-range visibility.
-
Mounting Flexibility: Comes with side and adjustable rear brackets for custom installs.
-
Weatherproof Construction: Rated IP68 & IP69K for full protection against dust, water, and pressure washing.
-
Durable Build: Impact-resistant housing and lens for harsh road or worksite conditions.
-
EMI Safe: R10 EMI compliant — safe for use near radios and sensitive electronics.
-
Plug-and-Play Simplicity: Includes 500mm lead to DT plug with 150mm DT fly lead for sealed, clean installs.
-
Color Temp: Crisp 5700K white light delivers clarity and daylight-style definition.
-
3-Year Warranty: Built with quality and backed by Noxsolis for long-term reliability.
Where Slim Meets Serious Performance
The NX801 is your go-to solution when mounting space is limited but light output matters. From sleek 4WD builds and modern bumpers to work vans, ATVs, or side-by-sides — this slimline bar tucks in cleanly and delivers exceptional lighting in all conditions.
Whether you’re cruising backroads or lighting up a jobsite, the NX801 offers wide coverage and long-distance confidence in a sleek form factor.
Vehicle & Application Compatibility
Perfect for:
-
Bumper, grille, or roof rack installs
-
4WD, UTV, and overland builds
-
Compact work trucks and utility vehicles
-
Farm equipment and side-by-sides
-
Trailers, enclosed carriers, and service vehicles
Compatible with 12V and 24V systems.
Technical Specifications
-
Light Output: 4,900 Lumens (Raw)
-
Power Consumption: 54W
-
Beam Distance: 1 Lux @ 450m
-
Beam Type: Combo (Spot + Flood)
-
Voltage Range: 12–24V DC
-
Current Draw: 3.9A @ 13.8V / 2.2A @ 24V
-
Color Temperature: 5700K
-
Waterproof Rating: IP68 & IP69K
-
Lens Material: Polycarbonate
-
Mounting: Side brackets + adjustable rear brackets
-
EMI Compliance: R10
-
Connector: 2-Pin DT (500mm lead + 150mm DT fly lead)
-
Weight: 0.64kg
-
Warranty: 3-Year Limited Warranty
What’s Included
-
1x NX801 11.5″ Slimline LED Light Bar (Combo Beam)
-
2x Side Mount Brackets
-
2x Adjustable Rear Brackets
-
Mounting Hardware
-
150mm DT Fly Lead
Now Available at BTS Lighting — Big Light. Small Profile. Maximum Versatility.
Whether you’re squeezing lights into a custom bumper or upgrading your utility setup, the NX801 Slimline LED Bar delivers a clean fit, serious beam reach, and pro-grade durability in one sleek package.
