Ram 1500 | 1500 Classic-SS3 LED Fog Light Kit
Features
-
Direct replacement for Ram 1500 & 1500 Classic factory fog lamps
-
SAE-compliant, road-legal beam patterns
-
Includes custom bezel and vertical bracket for a factory-style fit
-
Plug-and-play installation with included adapters
-
Advanced TIR optics for maximum efficiency and focus
-
Durable powder-coated aluminum die-cast housing
-
Engineered and assembled in the USA
Overview
Upgrade your 2013–2018 Ram 1500 or 2019-2024 Ram 1500 Classic’s lighting with the SS3 LED Fog Light Kit. Delivering higher output than any other 3” LED pod on the market, the SS3 is designed for unmatched performance and durability. Each light uses custom-engineered Total Internal Reflection (TIR) optics, focusing every lumen on the road where it’s needed most while minimizing glare. With its included bezel and vehicle-specific vertical brackets, this kit installs seamlessly for a clean, factory-style appearance—only brighter.
Plug & Play Installation
No cutting, splicing, or modifications required. Simply remove your stock fog lamps, bolt in the SS3 units, and connect using the included plug-and-play adapters. Installation takes just minutes.
Advanced TIR Optics
Unlike standard reflectors that waste light through glare and internal loss, the SS3’s patented TIR optics collect all light from the LEDs and direct it precisely on target. This results in superior efficiency, brightness, and clarity compared to basic lens or reflector designs.
SAE-Compliant Beam Patterns
Choose the beam style that fits your needs:
-
SAE Fog (FineLine Optic): A wide 80° field of view for maximum visibility in poor weather—ideal as a direct upgrade for factory fog lights. Available in cool white (6000K) or selective yellow (3000K) for added contrast in rain, snow, and fog.
-
SAE Driving: An 18×8° beam pattern engineered to supplement high beams, providing long-range illumination without excessive glare.
When properly aimed, both options meet SAE J583 (Fog) or SAE J581 (Driving) standards for street-legal use.
Backlight Functionality
Each SS3 LED pod features a distinctive amber backlight mode, illuminating the TIR optic for a modern accent light that enhances your Ram’s look on or off the road.
Output Levels: Sport, Pro, or Max
-
Sport: Best balance of performance and value.
-
Pro: Double the output power for serious brightness.
-
Max: Cutting-edge automotive emitters deliver extreme intensity—the ultimate upgrade for those who demand the best.
Built for Reliability
Tested to withstand -40°F to 185°F, moisture, vibration, and corrosion, the SS3 is built tough for real-world conditions. Backed by a lifetime warranty and engineered in the USA, you can count on consistent performance mile after mile.
What’s Included
-
(2) SS3 3” Standard LED Pods
-
(2) 9006 DT 4-Pin backlight tap wires
-
(2) Ram vertical mounting brackets
-
Mounting hardware
-
Installation guide
Quantity: Pair (Left and Right Side)
Warranty: Lifetime
Returns: 30-day, no restocking fee
Satisfaction Guarantee: 100%
Fitment
-
Application: Fog Light Replacement
-
Make: Ram
-
Model: 2013–2018 Ram 1500 or 2019-2024 Ram 1500 Classic
⚠️ Note: Not compatible with Rebel trim models. If your truck did not come equipped with factory fog lamps, additional hardware and wiring may be required.
Choose the correct Diode Dynamics configuration
| Manufacturer SKU | Configuration |
|---|---|
| DD7084 | SS3 Sport Type Ram Vert Kit ABL White SAE Fog |
| DD7085 | SS3 Sport Type Ram Vert Kit ABL Yellow SAE Fog |
| DD7087 | SS3 Pro Type Ram Vert Kit ABL White SAE Fog |
| DD7088 | SS3 Pro Type Ram Vert Kit ABL Yellow SAE Fog |
| DD7089 | SS3 Max Type Ram Vert Kit ABL White SAE Fog |
| DD7090 | SS3 Max Type Ram Vert Kit ABL Yellow SAE Fog |
Questions and answers
How do I choose the correct version?
Select the options that match the manufacturer SKU and configuration table on this page. The listed choices cover DD7084, DD7085, DD7087, DD7088, DD7089, DD7090; each row is a real product configuration.
What is included?
Two (2) SS3 3” Standard LED Pods; Two (2) Ram Vertical brackets; Two (2) 9006 DT 4-Pin backlight tap wires; Mounting hardware; Mounting guide
What vehicle details must match?
Match the stated model years, model and any bumper, trim or factory-equipment requirements. A kit for one bumper or fog-light opening is not automatically compatible with another configuration of the same vehicle.
Explore pod lights, vehicle-specific lighting kits and matching wiring harnesses.
Manufacturer warranty
Diode Dynamics provides a limited lifetime warranty for this product for eligible purchases from April 15, 2025. Commercial, industrial and fleet use is limited to 8 years. After the first 3 years, covered products require return for inspection and repair or replacement at the manufacturer’s discretion. Coverage applies to the specified lamp or component; bundled wiring and accessories follow their own published terms. Keep proof of purchase. Manufacturer approval and an RMA are required before return; labor and normal wear are excluded. Shipping obligations vary by location. See the manufacturer warranty terms for eligibility, exclusions and claim instructions.
