MORIMOTO XB EVO · LF2-532
Tri-Beam control. A bolder Tundra front end.
Give your 2014–2021 Toyota Tundra a complete left/right XB Evo headlight upgrade. Configurable white or amber running lights, distinctive turn signals and driver-requested Frost-Free lens heating bring style and function together.
- Left + rightOne complete headlight pair
- White / amber DRLsConfigurable signal modes
- Tri-Beam opticsLow + high beam

LIGHT WITH A PURPOSE
Tri-Beam: Bi-LED plus low/high reflector assists
Optics matched to the application
The main Bi-LED projector works with separate low- and high-beam reflector assists. Both the Evo and Evo Hybrid Tundra models use this Tri-Beam layout.
A complete assembly upgrade
Both housings and the listed installation accessories are included. This is a matched headlight pair, not a bulb conversion.
Control the pattern
Check every function and aim the beams after installation. Original-style mounts do not guarantee correct aim, especially after changes to vehicle height.

SEE THE MANUFACTURER’S COMPARISON
A closer look at the beam pattern
These are Morimoto’s comparison illustrations under the stated setup, rather than an independent BTS test. The baseline differs by graphic; factory LED, factory halogen and previous-generation XB assemblies are not interchangeable benchmarks.

YOUR FRONT-END SIGNATURE
Choose white or amber, then your signal style.
The supplied selector keys configure white or amber DRLs and sequential or fade-off turn signals. Choose the correct keys and wiring positions in the exact installation guide.
A multistage welcome sequence animates the lights at startup. It is a styling feature, not an increase in driving-light output.

FROST-FREE LENS HEATING
Request it when cold-weather conditions call for it

The logic-controlled 50W ceramic heating element and circulation fans warm the housing to help mitigate lens frost, snow and ice buildup during driving.
- With the vehicle running, wait until the welcome sequence completes.
- Flash the high beams four times within four seconds. The ambient sensor must read at or below 5°C / 41°F, and the other operating conditions must be satisfied.
- Two return flashes indicate active heating and fans. One acknowledges the request with conditional standby.
The system monitors lens and heater temperatures and battery voltage. It starts off at every ignition cycle; request it again when needed. The same four flashes within four seconds manually disable it.
This is an aid during inclement driving, not a system intended to melt heavy overnight snow accumulation.
If the request is not acknowledged, the guide recommends turning off auto high beams and trying again.
CHOOSE THE FEATURES YOU WANT
XB Evo or Evo Hybrid?
This listing is the LF2-532 XB Evo for the 2014–2021 Toyota Tundra. The other version is sold separately.
| Feature | XB Evo | XB Evo Hybrid |
|---|---|---|
| DRL colour | Configurable white or amber | Fixed white |
| Turn signals | Sequential or fade-off selectable | Fade-off |
| Frost-Free lens heating | Included; driver-requested | Not included |
| Standard welcome sequence | Included | Not included |
| Mode-selector keys | Included | Not included |
| Main optics | Bi-LED + low/high reflector assists | Bi-LED + low/high reflector assists |
Compare the Evo Hybrid pair for the same Toyota

BEFORE YOU ORDER
Match the year, model and original lamps
2014–2021 Toyota Tundra
Follow the separate wiring paths for halogen low/high with incandescent DRL, halogen low/high with LED DRL, or 2018–2021 LED reflector low/high with LED DRL. Retains OE-style motorized adjusters.
These are North American left-hand-drive/right-hand-traffic applications. Follow the exact equipment and connector path in the installation guide. Aftermarket exterior lighting can alter signal behavior.
KEEP THE FACTORY ADJUSTMENT FUNCTION
OE-style motorized adjusters
Morimoto’s exact Tundra application includes OE-style motorized adjusters. Follow the equipment-specific connection instructions and check the adjustment function after installation; the final beam aim still needs to be set.

BOTH SIDES. THE MATCHED HARDWARE.
What is supplied

- Headlights: One Pair (1x Right Hand / Passenger Side Headlight, 1x Left Hand / Driver Side Headlight)
- Accessories: 2x Halogen Input Harnesses, 2x LED Input Harnesses, 2x Magnet Mount Resistors, 1x Fuse Tap, 1x DRL Harness, 8x (Four Pairs) Mode Selectors, 2x Turn Signal Adapters, 2x Incandescent DRL Modules
Use the adapters and signal components appropriate to the truck’s original lighting. Optional Supercharged drivers and other accessories are separate selections; they are not required to complete the standard headlight pair.
FACTORY MOUNTING. CAREFUL WIRING.
Plan the install, then set the aim
- Identify the original lamp equipment and select the exact wiring branch in the guide.
- Fit the housings at the original mounting points. Install the supplied input adapters, resistors and DRL components as directed.
- The guide calls for a notch in the fuse-box lid to route the DRL wire and grommet. Factory mounting does not mean a modification-free installation.
- Secure the wiring clear of heat and moving parts. Test all functions and adjust the beam aim.
Download the official LF2-532 model-family installation guide
Follow the exact heater request, acknowledgement and operating-limit instructions in the guide.

AN OPTIONAL OFF-ROAD CONFIGURATION
Add the exact Supercharged driver pair
The matching optional accessory is LF2-DRVSC10. The headlights already include standard LED drivers; the optional pair replaces them when you deliberately select the off-road configuration.
Morimoto describes approximately 30% greater low/high-beam intensity with this application’s Supercharged drivers. This is the manufacturer’s comparison, not a BTS measurement or a guarantee in every condition.

THE EXACT LF2-532 CONFIGURATION
Specifications and replacement references
| Detail | Manufacturer specification |
|---|---|
| Traffic Pattern | LHD / Right Hand Traffic Only (US/CA Standard) |
| Output (Standard Drivers) | DOT (FMVSS108) Compliant (LB2V and UB2) |
| Output (Supercharged Drivers) | Off-Road use only |
| Main Optics | 1x Type 1 Ishida Optic Bi-LED, 1x Low-Beam Reflector Assist, 1x High-Beam Reflector Assist |
| Functions | Low, High, Park, Turn, DRL, Welcome, and Lens Heating |
| Turn Signal Modes | Sequential or Fade Off (Configurable) |
| DRL Colors | White or Amber (Configurable) |
| Frost-Free System | Logic-controlled 50w ceramic w/ circulation fans |
| Internal Finish | Two-Tone Piano Black and Titanium w/ contrasting textures |
| Side marker | Amber side reflex reflector (DOT compliant) |
Original-equipment reference numbers
81150-0C211, 81150-0C140, 81150-0C130, 81110-0C211, 81110-0C140, 81110-0C130, 81110-0C210, 81110-0C211, 81150-0C210, 81150-0C211
Cross-check these with the listed year, model and original lamp equipment.
Morimoto provides a 5-year limited manufacturer warranty. Coverage, exclusions and return authorization follow the manufacturer’s current policy. Keep your proof of purchase and contact BTS before removing a lamp for a suspected warranty issue.
SEE THE DESIGN
Watch the official overview
Morimoto’s official 2014–2021 Toyota Tundra model-family presentation. The video may show both Evo and Hybrid versions; the exact specifications and package above describe this listing.

The video loads only when you choose it. No autoplay. Product-family demonstrations may include other options; the exact package and compatibility notes on this page govern your selection.
CLEAR ANSWERS BEFORE CHECKOUT
Your XB Evo questions
Is this a pair or a single headlight?
One order supplies the complete driver-side and passenger-side assemblies with the accessories listed above.
Which original lights can this replace?
Match the model year and original halogen or LED equipment to the correct branch of the linked manufacturer guide. Ask BTS with a photograph of the lights and connectors if the truck has been modified.
Can I choose amber daytime running lights?
Yes. The supplied keys select white or amber DRLs and the supported sequential or fade-off turn-signal mode.
Does this exact version have heated lenses?
Yes. Request the Frost-Free system using the exact high-beam sequence after startup. It activates only when its temperature and operating checks allow.
Does the Tundra Hybrid lose the reflector assists?
No. Both listed Tundra Evo versions retain a Bi-LED projector plus low- and high-beam reflector assists. This differs from the 4Runner and Tacoma Hybrid optical layout.
Are Supercharged drivers included?
No. Standard drivers are supplied. LF2-DRVSC10 is the exact optional Supercharged pair for this application; it is for off-road use only in Canada and the United States.
Will Frost-Free clear heavy overnight snow?
It helps mitigate buildup during cold-weather driving. It is not a heavy overnight-snow defroster and defaults off after each ignition cycle.
Are these headlights road legal?
Morimoto identifies the standard-driver configuration as DOT/FMVSS108 compliant for its listed North American application. The optional Supercharged configuration exceeds the compliant intensity limits and is not for on-road use in Canada or the United States.
Is installation completely modification-free?
No. The original mounting points are used, but the exact guide calls for a notch in the fuse-box lid for the DRL wire. Complete the correct equipment-specific wiring steps and aim the lamps.
What warranty is included?
Morimoto lists a five-year limited manufacturer warranty. Keep proof of purchase and contact BTS for installation help or a suspected warranty issue.
