Morimoto XB Evo+ Type T fog lights are built for drivers who want real fog light performance, not just more brightness. The Evo+ design lets you switch between white and yellow output while maintaining a proper fog beam pattern in both colors.
With an advanced Ishida SAE Wide Fog optic, Osram white LEDs, Nichia yellow LEDs, and a wide 102-degree beam spread, these fog lights are designed to improve near-field and side-of-road visibility without overpowering your low beams.
Key Features & Benefits
Switchable White + Yellow Output
The XB Evo+ Type T fog lights let you switch between white and yellow output depending on driving conditions and preference.
Features include:
- White output mode
- Yellow output mode
- Switchable dual-color design
- No-compromise beam distribution in either color
- Designed for real fog light use
White output gives a crisp modern look, while yellow output helps provide a lower-glare appearance in poor weather and night driving conditions.
Ishida SAE Wide Fog Optic
The optic was designed in-house by Morimoto’s lead optical engineer, Yoshi Ishida.
Lighting details:
- Ishida SAE Wide Fog optic
- 102-degree horizontal beam spread
- 51 degrees left to 51 degrees right
- 6.3-degree vertical beam spread
- Strong side-to-side coverage
The result is a wide, controlled fog beam that focuses on practical visibility instead of simply chasing peak brightness.
Balanced Fog Light Performance
These fog lights are designed to provide a strong balance of width and intensity.
Performance details:
- 1,500 raw lumens in white mode
- 1,250 raw lumens in yellow mode
- 8,500 candela white intensity
- 7,000 candela yellow intensity
- 20.5 watts per light
The beam is designed to improve near-field and side coverage without creating excessive foreground glare.
OE-Style Fit & Installation
Morimoto XB Evo+ Type T fog lights are designed as direct replacements for compatible factory fog lights.
Installation benefits:
- Designed to match OE specifications
- Plug-and-play H11/H9/H8 connectors
- Integrated aiming adjusters
- Modification-free installation on compatible applications
- 10mm mounting screws included
Proper aiming is important after installation to get the best fog light performance and reduce glare.
Performance, Compatibility & Use Case
Known Vehicle Compatibility
These Morimoto XB Evo+ Type T fog lights fit select Toyota and Subaru applications, including Toyota 4Runner 2010-2024, Avalon 2007-2015, Camry 2007-2014, Corolla 2009-2016, Highlander 2008-2010, Matrix 2009-2013, Prius 2010-2016, Prius C 2012-2016, Prius V 2012-2016, RAV4 2006-2012 and 2016-2021, Sienna 2010-2016, Solara 2006-2008, Tacoma 2012-2023, Tundra 2014-2021, Venza 2009-2014, Yaris 2007-2016, and Subaru Legacy 2015-2017.
Always confirm your year, trim, factory fog light style, and connector type before ordering.
OEM Replacement Part Numbers
These fog lights are listed to replace Toyota part numbers:
- 81220-06071
- 81210-08020
Use the OE part number to help verify fitment before installation.
Application & Use Case
Designed for:
- Toyota fog light upgrades
- Subaru Legacy fog light upgrades
- Factory fog light replacement
- White/yellow dual-color fog lighting
- Poor-weather visibility upgrades
- Daily driving and adventure builds
- Trucks and SUVs that need wider fog light coverage
These are a strong choice for drivers who want a true performance fog light with the flexibility of white and yellow output.
Installation & Technical Details
Installation Overview
The XB Evo+ Type T fog lights are designed as direct replacement fog lights for compatible vehicles.
Installation details:
- Product type: Dual-color LED fog light set
- Output colors: White and yellow
- Input connector: H11/H9/H8 male
- Power: 20.5 watts each
- Optic: Ishida SAE Wide Fog
- Housing material: Die-cast aluminum
- Lens material: UV-resistant polycarbonate
- Lens coating: Proprietary hardened anti-UV protection
- Interior color: Gloss black with contrasting textures
- Aiming: Integrated adjusters
- Hardware: 8 × 10mm mounting screws included
- Warranty: 10 years
Professional installation is recommended for proper wiring, secure mounting, output switching, and final beam aiming.
Technical Specifications
Output & LED Specs
- White LED chips: Osram Oslon Compact PL KW CWLPM3.T1
- Yellow LED chips: Nichia NCSY131
- Raw luminosity, white: 1,500 lumens
- Raw luminosity, yellow: 1,250 lumens
- Intensity, white: 8,500 candela
- Intensity, yellow: 7,000 candela
- Power: 20.5 watts each
Beam & Compliance Specs
- Compliance: SAE J583 F3 / ECE R19
- Horizontal beam spread: 51L to 51R, 102 degrees
- Vertical beam spread: 1D to 7.3D, 6.3 degrees
- Optic: Ishida SAE Wide Fog
Build Quality, Compliance & Warranty
Build Quality
Morimoto XB Evo+ fog lights are designed, engineered, and tested to deliver high-performance fog light output with premium construction.
Build details include:
- Die-cast aluminum housing
- UV-resistant polycarbonate lens
- Proprietary hardened anti-UV lens coating
- OE-grade wiring and connections
- Gloss black interior with contrasting textures
- Integrated aiming adjusters
The lens coating is designed to resist cracking, fading, and yellowing from UV exposure.
Compliance
These fog lights are listed as compliant with:
- SAE J583 F3
- ECE R19
The supplied product information states these fog lights are compliant for on-road use in North America and the EU. Proper installation and aiming are still required.
Warranty Coverage
This Morimoto product includes a 10-year warranty.
What’s Included
Included:
- 2 × Type T Morimoto XB Evo+ Fog Lights
- 8 × 10mm Mounting Screws
- 2 × H11/H9/H8 Connectors
- 10-Year Warranty
Frequently Asked Questions About Morimoto XB Evo+ Type T Fog Lights
What makes the XB Evo+ different from the standard XB Evo fog light?
The XB Evo+ version adds switchable white and yellow output.
It is designed to maintain proper beam distribution in both colors, instead of sacrificing beam quality when switching color.
Are these fog lights white or yellow?
They are both.
The XB Evo+ Type T fog lights can switch between white and yellow output.
What vehicles do these fit?
These fit select Toyota and Subaru applications, including Toyota 4Runner, Tacoma, Tundra, RAV4, Camry, Corolla, Prius, Sienna, Venza, Yaris, and Subaru Legacy applications listed in the compatibility section.
Confirm your model year, trim, factory fog light style, and OE part number before ordering.
Do these fit Toyota Tacoma?
Yes. These fog lights are listed for Toyota Tacoma 2012-2023.
Confirm your factory fog light setup before ordering.
Do these fit Toyota 4Runner?
Yes. These fog lights are listed for Toyota 4Runner 2010-2024.
Confirm your fog light style and mounting setup before installation.
What connector do these use?
These fog lights use H11/H9/H8 male connectors.
They include one pair of H11/H9/H8 connectors.
Are these fog lights SAE compliant?
Yes. These fog lights are listed as compliant with SAE J583 F3.
They are also listed as compliant with ECE R19.
What is the beam spread?
The horizontal beam spread is listed as 102 degrees.
That means the beam is designed to provide wide side-to-side fog light coverage.
Are these just brighter than stock?
They are designed for more than brightness.
Morimoto focused on beam width, intensity balance, optic control, and SAE/ECE fog light performance instead of simply maximizing raw brightness.
What warranty is included?
This product includes a 10-year warranty.
