Jeep JK · 2007–2018
A dedicated fog beam for your JK
Replace the factory plastic-bumper fog lamps with a round SS3 pair. Choose fixed White or Yellow output in Sport, Pro or Max, with a separate amber accent backlight.
Match the factory bumper
For 2007–2018 Jeep Wrangler JK. A 2018 Wrangler may be JK or JL; identify the generation before ordering. Aftermarket bumpers, body hardware and other accessories need a separate clearance and mounting check.
The six choices here use Type M brackets for the factory plastic bumper. They replace existing fog lamps; a Jeep without factory fog equipment needs a separate wiring and mounting plan. No steel-bumper offer is included in this selector.
For a factory steel bumper, compare Type MR SS3 kits and match the Steel option. For selectable White/Yellow output, see Type M Dual Color DD8942 or Type MR Dual Color DD8943.

Choose power and fixed main-beam colour
White is 6000K; Selective Yellow is 3000K. These six SKUs do not switch main-beam colour. Sport uses 14.5 W, Pro 36 W and Max 38.5 W per pod. All six use the SAE Fog pattern; Driving is not an option on this page.
| SKU | Power level | Main beam | Package |
|---|---|---|---|
| DD7044 | Sport | White SAE Fog | Two fixed-colour SAE Fog pods |
| DD7045 | Sport | Yellow SAE Fog | Two fixed-colour SAE Fog pods |
| DD7047 | Pro | White SAE Fog | Two fixed-colour SAE Fog pods |
| DD7048 | Pro | Yellow SAE Fog | Two fixed-colour SAE Fog pods |
| DD7049 | Max | White SAE Fog | Two fixed-colour SAE Fog pods |
| DD7050 | Max | Yellow SAE Fog | Two fixed-colour SAE Fog pods |

The amber backlight is a separate low-power accent, not the fog beam. Proper aiming is required; check applicable rules for road use.
What the pair includes
Two round SS3 fog pods, two Type M brackets, 9006 and 5202 adapter pairs, backlight tap wiring and mounting hardware.


Mount, connect and aim
Reuse the original fog-light fasteners. Connect the main beam through the supplied adapters and wire the optional backlight to a fused 12V source. Do not connect the backlight tap directly to the battery. Aim at 25 feet with the cutoff four inches below lamp-centre height.
Open the illustrated Type M/MR fog installation guide
Manufacturer mounting and aiming demonstration; match your actual JK bumper.
Manufacturer product demonstration; this page offers the fixed-colour Type M configurations listed above.
Manufacturer coverage
Diode Dynamics lists a limited lifetime warranty for these Stage Series pods and eligible off-road mounting brackets. Wiring, covers and other accessories have their own terms. Commercial, industrial and fleet use is limited to eight years. Coverage is subject to the manufacturer’s conditions and original-purchaser requirements. Read the manufacturer warranty
